MIL-DTL-6060E
HEAT-SEALED SEAM
BOLT
NUT
METAL
WASHER
LOCKWASHER
BARRIER MATERIAL
WOOD BASE
GASKETS
6 X 6 X 3/4 IN.
METAL WASHER
NOTE: Sizes of bolt and washers shall be appropriate for inside diameter of gasket under test.
FIGURE 1. Gasket mounting integrity test assembly.
